| Part No. | VRWM .max (V) | VBR .min (V) | CJ .typ (pF) | Ppp @8/20μs (W) | Ipp @8/20μs (A) | IR .max (μA) | Contact (kV) | Channel | Inner Diagram | Package | |
| JES0402-5V-C | 5 | 5.8 | 10 | 100 | 8 | 0.2 | ±30 | 1 |  | 0402 |  |
| JES0402-5V-LC | 5 | 6 | 2.5 | - | - | 0.2 | ±8 | 1 | | 0402 | |
VRWM：Reverse Working Voltage
VBR：Snap-Back Voltage
CJ：Junction Capacitance
Ppp：Peak Pulse Power
Ipp：Peak Pulse Current
IR：Reverse Leakage Current
Contact：IEC 61000-4-2;Contact Discharge
